Introducing Vision Machine's Decanter Centrifuge Line-Up

Featured Image

From decanter centrifuges that remove liquids from solids, refining processes, or waste minimization, to centrifuge repair, centrifuge parts, and centrifuge controls; Vision Machine Inc. has a separation system to meet your needs.

Vision decanter centrifuges are versatile, robust, and come in a range of sizes that can adjust to many types of processes and materials. Our machines are easy to operate and service with minimal resources. Utilizing patented technology, we provide an effective low maintenance solution.

Decanter Centrifuge Manufacturing

Our machines are designed by people who have repaired, serviced, operated and maintained centrifuges, both in the field and in the shop.

From 10" up to 24" bowl diameter, Vision Machine manufactures a full line of decanter centrifuges, and can adapt to virtually all types of processes and materials.

Series 10

Inside Bowl Dimensions 10” x 35”

Series 10-1-1

  • Main Motor – 20HP @ 3600 rpm 230/460 V
  • Back Drive Motor – 5HP @ 3600 rpm 230/460 V
  • Gearbox and Ratio – Planetary Gearbox 76:1 ratio, Max Output torque 15,000 in/lbs
  • Max Pinion Input torque – 197 in/lbs

Series 14

Inside Bowl Dimensions 14” x 48”

Series 14-2-1

  • Main Motor – 40HP @ 1800 rpm 230/460 V
  • Back Drive Motor – 15HP @ 1800 rpm 230/460 V
  • Gearbox and Ratio – Planetary Gearbox 52:1 ratio, Max Output torque 18,000 in/lbs
  • Max Pinion Input torque – 346 in/lbs

Series 17

Inside Bowl Dimensions 16.5” x 55.5”

Series 17-1-1-1

  • Main Motor – 75HP @ 1800 rpm 230/460 V
  • Back Drive Motor – 25HP @ 1800 rpm 230/460 V
  • Gearbox and Ratio – Planetary Gearbox 53:1 ratio, Max Output torque 36,000 in/lbs
  • Max Pinion Input torque – 679 in/lbs

Series 20

Inside Bowl Dimensions 20” x 70”

Series 20-1

  • Main Motor – 125HP @ 1800 rpm 230/460 V
  • Back Drive Motor – 40HP @ 1800 rpm 230/460 V
  • Gearbox and Ratio – Planetary Gearbox 98:1 ratio, Max Output torque 90,000 in/lbs
  • Max Pinion Input torque – 918 in/lbs

Series 24

Inside Bowl Dimensions 24” x 84”

Series 24-1-1

  • Main Motor – 150HP @ 1800 rpm 230/460 V
  • Back Drive Motor – 50HP @ 1800 rpm 230/460 V
  • Gearbox and Ratio – Planetary Gearbox 95:1 ratio, Max Output torque 180,000 in/lbs
  • Max Pinion Input torque – 1,894 in/lbs

Serving Diverse Industries

Vision Machine Inc. offers the right technologies and suitable service solutions for various products in various industries, including:

  1. Oil and gas
  2. Refining / Petrochemical
  3. Agriculture
  4. Municipal
  5. Rendering
  6. Food and beverage
  7. Horizontal directional drilling

Download our Specification Sheet

Download our Specification Sheet today and learn more about our line of decanter centrifuges.

New call-to-action


About Vision Machine

Vision Machine Inc. specializes in the manufacturing and repair of horizontal decanter centrifuges and has been doing so since 2004.

At Vision Machine, Inc., we pride ourselves on providing our customers with the highest value, lowest total cost of ownership and easiest to operate separation systems available. All proudly made in America at our Spring, TX facility.
